Get Ready for the Sun


Avery Dennison® Automotive Window Films
NR Pro Series Non-Reflective Film


OPTICAL & SOLAR PROPERTIES

If you have any questions, or if you need assistance, please do not hesitate to contact our customer service department:

Toll Free: 1.866.258.6908

Automotive Window Tint Installation Guide

1. Prepare the Windows

• Clean the Windows: Start by thoroughly cleaning the windows with an ammonia-free glass cleaner. Avoid products with ammonia, as they can interfere with tint adhesion.
• Use a Razor Blade: Scrape the glass with a razor blade to remove any dirt, dust, or adhesive residue, especially along the edges.
• Wipe with a Lint-Free Cloth: After cleaning, use a lint-free cloth to dry the surface completely and remove any remaining particles.

2. Measure and Cut the Tint Film

• Measure the Windows: Measure each window and cut the tint film slightly larger than the window dimensions. This will allow you to trim the film precisely once it’s applied.
• Pre-Cut or Use Templates: Some tint films come pre-cut, or you can use templates for a more straightforward application, especially for rear windows or irregular shapes.

3. Prepare an Installation Solution

• Mix a Slip Solution: Use a spray bottle to mix water with a few drops of baby shampoo or dish soap. This solution helps the tint slide and adhere smoothly without sticking immediately.
• Label Your Bottles: Clearly label the bottle to avoid confusion and ensure a consistent application.

4. Apply the Tint to the Window

• Spray the Window with Slip Solution: Spray a generous amount of slip solution on the inside surface of the window. This layer will allow you to position the film accurately.
• Peel and Position the Tint: Carefully peel the backing from the tint film and spray the adhesive side with the solution to prevent it from sticking prematurely. Position the film on the wet window surface.
• Align and Adjust: Adjust the film until it’s in the right position, using the excess around the edges as a guide.

5. Smooth and Secure the Film

• Use a Squeegee: Starting from the center, use a squeegee to push out the slip solution and air bubbles, working toward the edges. This ensures the film bonds properly and reduces streaking.
• Work in Small Sections: Divide the window into sections for better control, using even pressure to secure the film smoothly.

6. Trim Excess Tint

• Careful Trimming: Use a sharp utility knife to trim any excess film around the edges of the window. Apply light pressure to avoid damaging the glass.
• Seal the Edges: Press down along the edges to ensure a good seal, which prevents peeling and water intrusion.

7. Final Inspection and Drying Time

• Check for Bubbles: If you notice small bubbles or creases, use a heat gun on low to medium heat to smooth them out carefully. Avoid overheating.
• Allow Time to Cure: Avoid rolling down or cleaning the tinted windows for at least 24-48 hours to let the adhesive bond fully.

Handy Tools and Supplies for Window Tint Application

1. Essential Tools

• Squeegee with Soft Edge: A soft-edge squeegee ensures smooth application without scratching the tint film.
• Utility Knife: Use a sharp utility knife for precise trimming. Replace the blade as needed for clean cuts.
• Spray Bottle: For the slip solution, a quality spray bottle is essential. Make sure the spray is even to prevent oversaturation.

2. Cleaning and Preparation Supplies

• Ammonia-Free Glass Cleaner: Essential for a clean surface without leaving residues that can interfere with the tint adhesive.
• Lint-Free Cloths or Microfiber Towels: Ideal for drying the windows and wiping down any excess solution without leaving fibers behind.
• Razor Blade or Scraper: A razor blade removes any embedded dirt, stickers, or adhesive residue, which is crucial for a flawless finish.

3. Tools for Removing Air Bubbles and Wrinkles

• Heat Gun: A heat gun can help stretch and set the tint film, especially on curved windows, and remove any stubborn bubbles.
• Air Release Tool: Use a small pin tool to gently pop any tiny air bubbles trapped under the film without leaving noticeable marks.

4. Application Helpers for Curved Windows

• Heat Forming Tools: For heavily curved rear windows, tools like a heat gun and shrink wrap can help you shape the film to fit perfectly.
• Wrap Glove or Tint Glove: This glove protects the film from fingerprints or smudges as you press and smooth it into position.

5. Post-Installation Tools

• Edge Seal Tape (Optional): Useful for edges or areas that may be exposed to moisture, ensuring the tint stays in place.
• Tint-Safe Detailer or Cleaner: Use a window tint-safe cleaner to keep your tint looking fresh and clean without damaging the film.
