3M COLORED PPF / PWF SERIES GLOSS HABANERO RED PAINT PROTECTION FILM | PWF-G43

3M PWF Colored PPF Series

The Ultimate Fusion of Style and Protection...

Why Choose 3M Protection Wrap Film (PWF)?

• Dual Benefit: Personalization & Protection – Get the stylish color change of a vinyl wrap with the robust shielding of PPF.


• Easy Dry Application – Unlike traditional PPF, PWF applies without the need for fluid or heat, reducing installation time by up to 50%.


• Self-Healing Technology – Minor scratches and swirl marks disappear with the application of heat, keeping your wrap looking pristine.


• Mirror-Like Finish – Once the cap sheet is removed, PWF reveals a high-gloss, flawless surface.


• Advanced 3M Adhesive Technology – Features 3M™ Controltac™ for easy repositioning and 3M™ Comply™ air release channels for a bubble-free, seamless application.


• Superior Thickness & Durability – At 8 mil (0.2mm), PWF is 70% thicker than standard vinyl wraps, offering long-lasting resilience.


• 10-Year Warranty – Backed by 3M, ensuring reliability and peace of mind.


• Versatile Applications – Perfect for full vehicle wraps, partial wraps, accents, racing stripes, and more.

Engineered for Performance

• Cold Stretch Capable – Conforms effortlessly to deep recesses without excessive heat.

• Stain Resistant – Repels dirt, water, and environmental contaminants, ensuring easy maintenance.

• Permanent yet Removable – Designed for long-term durability but can be professionally removed without damaging the underlying paint.

• Knifeless Tape Compatible – Works seamlessly with 3M™ Knifeless Precision Tape for precise, clean cuts.

Technical Specifications

• Material: Polyurethane

• Thickness: 8.0 mil (0.2mm)

• Application Type: Dry (No Fluid Required)

• Adhesive Type: Acrylic-based, air egress for easy installation

• Durability: Up to 10 Years

• Width: 60 inches (5 feet)

• Max Roll Length: 75ft / 25yards


Applications

• Full Vehicle Wraps

• Paint Protection

• Racing Stripes

• Hoods, Roofs, and Trunks

• Motorcycle Wraps

• Boat & Jet Ski Wraps

• Emblem & Trim Wraps

• Appliance & Furniture Wraps

• Decals & Custom Graphics

The Future of Wrap Films is Here

3M Protection Wrap Film is the ultimate choice for professionals and enthusiasts looking to combine aesthetics with durability. Whether you want to enhance the look of your vehicle, protect it from everyday hazards, or create unique designs, PWF delivers superior results with minimal effort.


Colored Paint Protection Film (PPF / PWF) Application Guide

1. Prepare the Surface

• Clean Thoroughly: Wash the surface with an automotive-grade soap to remove dust, dirt, and grease. Avoid using wax or silicone-based cleaners, as they can interfere with adhesion.
• Inspect for Imperfections: Check for scratches, dust, or paint defects. Address these issues before application, as imperfections may show through the film.

2. Measure and Cut the Film

• Measure Carefully: Accurately measure the area to be wrapped, allowing extra material for trimming.
• Pre-Cut if Necessary: For large or complex areas, consider pre-cut templates for easier installation and precise fitment.

3. Dry Application Process

Unlike traditional wet application PPF films, 3M PWF Colored PPF is installed using a dry application method. This requires precise handling and positioning.

Positioning the Film

• Peel and Align: Remove the backing liner and gently position the film on the surface without applying pressure.
• Use Wrap Magnets: These help hold the film in place while adjusting alignment, particularly for large panels.

Applying the Film

• Start from the Center: Use a soft, non-marring squeegee to press the film onto the surface, starting from the middle and working outward.
• Apply Even Pressure: Use firm, overlapping strokes to remove air pockets and ensure strong adhesion.
• Use Heat for Curves: Apply gentle heat (90-120°F) using a heat gun or infrared heater to conform the film around complex curves and recesses.
• Work in Sections: To maintain control, divide the application into manageable sections and complete one area at a time.

4. Removing Air Bubbles and Wrinkles

• Squeegee Technique: Use a felt-edge or soft squeegee to press out bubbles while ensuring even pressure.
• Air Release Tool: If small air bubbles remain, use an air release tool (or a fine pin) to carefully puncture the bubble and smooth it out.

5. Trimming and Finishing

• Trim Excess Film: Use a precision utility knife or 3M Precision Line Knifeless Tape to achieve clean, accurate cuts. Avoid applying excessive pressure to prevent damage to the paint.

Edge Sealing

• Use PPF Edge Seal Tape on areas prone to lifting, such as edges, corners, and high-impact zones.
• Apply firm pressure along the edges to ensure proper adhesion.

6. Final Inspection and Curing

• Inspect for Imperfections: Check for any lifting edges, bubbles, or wrinkles. Reheat and reapply pressure where needed.
• Allow to Cure: Let the film fully cure for 24-48 hours before washing or exposing it to extreme conditions.

Handy Tools and Supplies for Dry Application PPF

1. Essential Tools

• Soft Squeegee: Prevents scratches while ensuring proper adhesion.
• Utility Knife: For precise trimming.
• Wrap Magnets: Holds the film in place during positioning.
• Heat Gun or Infrared Heater: Helps contour the film around curves.

2. Surface Preparation Supplies

• Cleaning Solution with Water
• Lint-Free Cloths: Ensures a clean surface without leaving fibers.

3. Finishing Tools

• 3M Precision Line Knifeless Tape: Provides clean, precise cuts without using a blade.
• Edge Seal Tape: Prevents film lifting in high-stress areas.
• Microfiber Towels: Keeps the film clean and free of fingerprints during installation.

3M Precision Line Knifeless Tape for Dry PPF Application

Why Use Knifeless Tape?

• Safe Cutting: Prevents accidental damage to the vehicle’s paint.
• Precise Edges: Achieves sharp, clean cuts on complex contours.
• Seamless Integration: Ideal for multi-panel installations and custom designs.

How to Use It

1. Apply the Tape: Position the knifeless tape along the desired cut line before laying down the PPF film.
2. Install the Film: Apply the film as usual, ensuring it conforms to the tape’s placement.
3. Pull the Filament: Once the film is secured, pull the embedded filament to cut the film cleanly along the tape’s path.
4. Remove the Tape: Carefully peel off the knifeless tape, leaving a precise edge without the need for a blade.

By following these steps and using the recommended tools, you can achieve a clean, professional, and durable installation of 3M PWF Dry Application Colored PPF Film.
